Original X431 GX3 is a new automotive diagnostic product and designed by LAUNCH with the technology of 'Open Control Platform for Vehicle' representing the highest level of automotive diagnostic technology in the world. It has the function of read DTCs, read datastream, actuation test, sensor waveform display and ECU coding.
Update methods: EMAIL
Original Launch X431 GX3 Auto Diagnostic Tool
Update methods: Email update
Here is the video tell you how to use this product:
http://x431usa.com/productdemo/index2.htm?Submit=Start+Demo+%3E%3E
X431 GX3 Description:
X431 GX3 is a new automotive diagnostic product and designed by LAUNCH with the technology of 'Open Control Platform for Vehicle' representing the highest level of automotive diagnostic technology in the world. It has the function of read DTCs, read datastream, actuation test, sensor waveform display and ECU coding. It's faster to communicate with cars than X-431 by integrated structure to save time in work. It can test most of cars by using the unique 16 PIN connector which integrates the function of all 16 PIN connectors of X-431. 24V operating voltage capability is added to work with different kinds of batteries. It is easier and more conveniet to operate than X-431 based on the smart design.
Launch X431 GX3 Function:
read DTCs,read datastream, actuation test, sensor waveform display and ECU coding
Launch GX3 Specification:
1.Features
1)Inherited with all diagnosis function of X-431
2)Faster communication with cars than X-431 by integrated design to save time in work
3)All inclusive software coverage - European, American and Asian
4)24V operating voltage capability is added to work with different kinds of batteries
5)Test most of cars by using unique & integrated 16 PIN connector
6)Easier and more conveniet to operate than X-431 based on the smart design
7)Upgrade software through email.
2.X431 GX3 Parameter:
Dimension:60CM*17CM*42CM
Linux
Memory:16M
CF Card:512M
Main Unit I/O:Universal serial port/parallel port
Power Supply:DC 12V / 24V
Power:Approx. 9W
Screen:240X320 LCD touch screen with background light
Printer:Mini high speed thermal printer
Ambient Temperature:-15°C～50°C
Relative Humidity:<90
X431 GX3 Picture Display:
